175966-2
Manufacturer:
TE Connectivity
Mfr.Part #:
175966-2
Datasheet:
Description:
Headers and Wire Housings Cable, Free Hanging Plug, Socket Number of Positions:16 Pitch:2.5 mm
| Parameter | Value |
|---|---|
| Length | 23.3 mm |
| Width | 18.0086 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -22 °C |
| Height | 23 mm |
| Material | Polybutylene |
| Packaging | Bulk |
| Depth | 23 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Pitch | 2.5 mm |
| Orientation | Straight |
| Lifecycle Status | Production (Last Updated: 2 weeks ago) |
| Color | Black |
| Gender | Male |
| Number of Contacts | 16 |
| ELV | Compliant |
| Body Material | PBT |
| Connector Type | Plug, Socket |
| Number of Positions | 16 |
| Number of Rows | 2 |
| Row Spacing | 5.207 mm |
| Housing Material | Polybutylene |
| Fastening Type | Latch |
| Circuit Application | Signal |
| Housing Color | Black |
| Mating Tab Width | 1 mm |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
| Polarized | Yes |
| Hybrid Connector | No |
| Serviceable | No |
Stock: 360
Distributors
pcbx
pcbxUnit Price$0.76445
Ext.Price$0.76445
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.76445 | $0.76445 |
| 10 | $0.64176 | $6.41760 |
| 25 | $0.60001 | $15.00025 |
| 50 | $0.56098 | $28.04900 |
| 100 | $0.52448 | $52.44800 |
| 300 | $0.50607 | $151.82100 |
| 500 | $0.48830 | $244.15000 |
| 1000 | $0.46861 | $468.61000 |
